WAGO 2002-1661 Base terminal 5.20 mm Pull spring Configuration: L Grey 1 pc(s) Piece

EAN:
Part number:
Item no:
Grey terminal housing with multiple plug connections and metal contacts.
Packaging type
Piece
Product type
Base terminal
Connection
Pull spring
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
2.50 mm²
Datasheet (PDF)
Fast track dispatch on Tue 27 Oct
194 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 3.79 / piece)
€ 4.29
-12 %
€ 3.79
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

WAGO 2002-1661 Base terminal 5.20 mm Pull spring Configuration: L Grey 1 pc(s) Piece

  • Symbol image for WAGO 2002-1661 Base terminal 5.20 mm Pull spring Configuration: L Grey 1 pc(s) Piece

Technical specifications

Packaging type

Piece

Product type

Base terminal

Connection

Pull spring

Configuration

L

Cross section (flexible) (min.)

0.25 mm²

Cross section (flexible) (max.)

4 mm²

Cross section (inflexible) (min.)

0.25 mm²

Cross section (inflexible) (max.)

2.50 mm²

AWG (min.)

22

AWG max.

12

Clamp width

5.20 mm

No. of rows

1

Pins per row

2

Number of pins

2

Factory colour

Grey

Nominal current

16 A

Nominal current - rounded value

16 A

Nominal voltage

250 V

Min. stripping length

10 mm

Stripping length (max.)

12 mm

Manufacturer part #

2002-1661

Content

1 pc(s)

Type

2002-1661

Width

5.20 mm

Connector colour

Grey

Nominal current (details)

-

Connection

-

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 731888 WAGO 2002-1661 Base terminal 5.20 mm Pull spring Configuration: L Grey 1 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 731888 WAGO 2002-1661 Base terminal 5.20 mm Pull spring Configuration: L Grey 1 pc(s) Piece
