WAGO 2016-1207 PG terminal 12 mm Pull spring Configuration: Terre Green, Yellow 1 pc(s)
EAN:
Part number:
Item no:
Product type
PG terminal
Connection
Pull spring
Cross section (flexible) (max.)
24 mm²
Cross section (inflexible) (max.)
16 mm²
Nominal current - rounded value
76 A
Datasheet (PDF)
Number
Total (€ 7.49 / piece)
€ 7.49
incl. VAT
14-day return policy included
Highlights & Details
WAGO 2016-1207 PG terminal 12 mm Pull spring Configuration: Terre Green, Yellow 1 pc(s)
- Durchgangsklemme
- TOPJOB®S
- CAGE CLAMP®
Technical specifications
- Product type
PG terminal
- Features
+ CAGE CLAMP®
- Connection
Pull spring
- Configuration
Terre
- Cross section (flexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
24 mm²
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (inflexible) (max.)
16 mm²
- AWG (min.)
20
- AWG max.
4
- Clamp width
12 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Factory colour
Green
Yellow
- Nominal current
76 A
- Nominal current - rounded value
76 A
- Min. stripping length
18 mm
- Stripping length (max.)
20 mm
- Manufacturer part #
2016-1207
- Content
1 pc(s)
- Type
Durchgangsklemme
- Dim
(W x H) 12 mm x 36.9 mm
- Width
12 mm
- Height
36.9 mm
- Rated surge voltage
8 kV
- Weight
814.00
- Type
2-conductors
- Nominal current (details)
76 A
- Cross section
0.5 - 10/16 (rigid / flexible) mm²
- Connection
-
DIN rail (top hat rail) 35 mm
Green/yellow
12
69.8 mm
36.9 mm
105-105 °C
V0
TRUE
Spring clamp connection
Spring clamp connection
1
2
2.5-16 mm²
2.5-16 mm²
0.5-25 mm²
0.5-16 mm²
Thermoplastic
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 735619 WAGO 2016-1207 PG terminal 12 mm Pull spring Configuration: Terre Green, Yellow 1 pc(s)
User & Safety Instructions
User & Safety Instructions 735619 WAGO 2016-1207 PG terminal 12 mm Pull spring Configuration: Terre Green, Yellow 1 pc(s)
Description
The direct plug-Series 2016 protects against handling errors and allows simple plug of single-wire and stranded conductors.
