WAGO 2706-103 Spring-loaded terminal 6.00 mm² Number of pins 3 Grey 55 pc(s)
Product type
Spring-loaded terminal
CS
7.50 mm
Pins per row
3
Number of pins
3
Connection
Spring-loaded terminal
Print
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Spring-loaded terminal
- Content 55 pc(s)
Technical specifications
- Type
2706-103
- Product type
Spring-loaded terminal
- Features
+ CAGE CLAMP®
- CS
7.50 mm
- No. of rows
1
- Pins per row
3
- Number of pins
3
- Series
2706
- Min. stripping length
11 mm
- Stripping length (max.)
12 mm
- Connection
Spring-loaded terminal
Print
- Cross section (flexible) (min.)
0.50 mm²
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
6.00 mm²
- Cross section (inflexible) (max.)
6.00 mm²
- AWG (min.)
20
- Connector orientation
At an angle (to the PCB)
- AWG max.
10
- Contact material
Cathode copper, tin plated
- Factory colour
Grey
- Wire protection
Yes
- Weight
15.419 g
- Manufacturer part #
2706-103
- Industrial packaging
Yes
- Content
55 pc(s)
- Nominal voltage
630 V
- Width
30.00 mm
- Height
26.00 mm
- Length
22.50 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 655781 WAGO 2706-103 Spring-loaded terminal 6.00 mm² Number of pins 3 Grey 55 pc(s)
User & Safety Instructions
User & Safety Instructions 655781 WAGO 2706-103 Spring-loaded terminal 6.00 mm² Number of pins 3 Grey 55 pc(s)
