WAGO 870-911 Continuity 5 mm Pull spring Configuration: L Grey 100 pc(s)
Product type
Continuity
Connection
Pull spring
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
2.50 mm²
Nominal current - rounded value
24 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
2-conductor through terminal
- 870-911
Technical specifications
- Product type
Continuity
- Features
+ CAGE CLAMP®
- Connection
Pull spring
- Configuration
L
- Cross section (flexible) (min.)
0.08 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.08 mm²
- Cross section (inflexible) (max.)
2.50 mm²
- AWG (min.)
28
- AWG max.
12
- Clamp width
5 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Factory colour
Grey
- Nominal current
24 A
- Nominal current - rounded value
24 A
- Nominal voltage
500 V
- Min. stripping length
6 mm
- Stripping length (max.)
6 mm
- Manufacturer part #
870-911
- Content
100 pc(s)
- Industrial packaging
Yes
- Type
870-911
- Dim
(L x W x H) 5 x 5 x 26.50 mm
- Width
5 mm
- Height
26.50 mm
- Length
5 mm
- Contamination level
3
- Weight
3.963 g
- Flammability rating
V0
- Connector colour
Grey
- Insulation material
Thermoplastic
DIN rail (top hat rail) 15 mm
Grey
5
34.5 mm
26.5 mm
500 V
105-105 °C
V0
TRUE
Spring clamp connection
Spring clamp connection
1
2
FALSE
0.08-2.5 mm²
0.25-2.5 mm²
0.08-4 mm²
0.08-2.5 mm²
Thermoplastic
24 A
FALSE
- UKCA
not relevant
