Walther Werke 986970084 Electric bike charging station
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Housing material: Other
- 4G (LTE) mobile phone standard: No.
- With display: No.
- Frequency: 50 Hz
- Compatible with Apple HomeKit: No.
- Compatible with Amazon Alexa: No.
- Compatible with Google Assistant: No.
- IFTTT support available: No.
- Input voltage: 400 V
- Rated connection power 4 kW
- Number of loading points: 9
- Max. Power per charging point 1.4 kW
- With house connection box (HAK): No.
- Number of FI switches type A: 9
- Charging cable permanently lockable on the charging station: No.
- DC fault current detection: No.
- Contactor contact welding detection: No.
- With circuit breaker: No.
- Network-compatible as Master: No.
- Network-compatible as Extender: No.
- Network-compatible via LAN: No.
- Network-compatible via WLAN: No.
- Mobile phone standard 5G: No
- With energy meter: No.
- With key switch: No.
- With integrated RFID card reader: No.
- NFC (Near Field Communication): No.
- Static load management integrated: No.
- Suitable for dynamic load management: No.
- Plug and charge (ISO 15118): No.
- Operation and configuration via APP: No.
- Export of the load history: No.
- Backend included: No.
- With MID-compatible energy counter: No.
- True-to-law: No.
- Number of household sockets: 18
- Product type
Electric bike charging station
- Width
1264 mm
- Height
1849 mm
- Depth
463 mm
- No. of ports
9
IP44
IK09
- No. of phases
3-phase
- Charging capacity
4 kW
Documents & Downloads
Datasheet
Datasheet 3836360 Walther Werke 986970084 Electric bike charging station
User & Safety Instructions
User & Safety Instructions 3836360 Walther Werke 986970084 Electric bike charging station
Description
Walther pedal column CUBE housing made of aluminum and steel plate with heavy metal free powder coating Colour: DB703-iron-glimmer gray with holes for mounting on foundations or ground pieces Self closing door incl. magnetic holder Cable design possible with closed door Supply compartment with cylinder pre-driver Connection possibility: 1x5x10mm² Protection type Electronics: IP44 Protection type Total: IP23 (due to cable design) Impact resistance: IK09 Size approx.: 1850 x 1260 x 460mm / H-B-T 9 Charging compartments Internal dimensions 290 x 330 x 350mm / H-B-T approx. 30l. Capacity: 2 safety sockets 16A 2P 230V with increased protection against contact with RCBO combination 2P 6A/0.03A B - Type A- Closure per compartment: PIN lock - authentication method four-digit code - status LED - acoustic signal - battery operated - battery compartment lid secured against unauthorized opening - shock resistance IK09 - protection class: IP54 - temperature range: from -15°C to 42°C.
This text is machine translated.
This text is machine translated.
