Walther Werke FW210506BT FW210506BT CEE plug 16 A 5-pin 200 V, 415 V 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 209.99 / piece)
€ 209.99
incl. VAT
14-day return policy included
Highlights & Details
CEE NEO IPD plug one-touch 16A 5P 6h
- CEE NEO IPD plug one-touch 16A 5P 6h
- Protection class IP54
- With BLT and screw technology
- This text is machine translated.
Technical specifications
- Voltage according to IEC 60309 (series I)200/346 V - 240/415 V
- Time setting 6 h
- Colour code red
- Protection class (IP) IP54
- Connection technology: Screw less terminal
- Cable inlet: Kink protection bushing
- With straight plug
- Material: Plastic
- Contact material CuZn
- Surface treatment: Contacts untreated
- Conductor cross-section (rigid): 1.5 - 4 mm²
- Conductor cross-section (flexible): 1 - 2.5 mm²
- Cable diameter 8 - 17 mm
- Sheath length (L, N) 40 mm
- Sheath length (PE): 60 mm
- Stripped insulation length 7 - 8 mm
- Max. Torque of screw connection 0.8 Nm
- Flammability class of housing: V2
- Flammability class of the contact carrier: V0
- Product type
CEE plug
- Nominal voltage
200 V
415 V
- Nominal current
16 A
- Nominal current - rounded value
16 A
- Type A
CEE plug (5-pin, 16 A)
- Max. capacity
16 A
- Factory colour
Black
- Dim
(L x W x H) 300 x 150 x 100 mm
- Length
300 mm
- Width
150 mm
- Height
100 mm
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3015692 Walther Werke FW210506BT FW210506BT CEE plug 16 A 5-pin 200 V, 415 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3015692 Walther Werke FW210506BT FW210506BT CEE plug 16 A 5-pin 200 V, 415 V 1 pc(s)
Description
Features
- With screwing technology
- 16A 5P 6H IP54 200/346V - 240/415V~
- With red color ring coding
- Housing made of PA6 material
- With highly heat resistant contact carrier made of PA66 material
- IPD with BLT
- And automatically activated strain relief
Scope of delivery
- CEE NEO IPD plug one-touch 16A 5P 6h
- User manual.
