Wiha 29233 Workshop Torque screwdriver 5 - 14 Nm DIN EN ISO 6789, DIN EN 26789
EAN:
Part number:
Item no:
Number
Total (€ 151.25 / piece)
€
Only 7 Piece(s) available
Highlights & Details
TorqueVario ® STplus cross-grip torque tool.
- Torque can be set via numerical scale
- With slipping clutch
Technical specifications
- Hexagon head: 6 mm
- Range of use
Workshop
- Drive
6 mm
- Torque (min.)
5 Nm
- Torque (max.)
14 Nm
- Tolerance ±
6 %
- Length
80 mm
- Handle length
120 mm
- Material
Chromium-vanadium steel
- Material properties
tempered
- Width
45 mm
- Height
160 mm
- Weight
375 g
- DIN standard
DIN EN ISO 6789
DIN EN 26789
- Screwdriver features
Multi-purpose tool grip
T-grip
adjustable
- Material (details)
Octagonal profile with hole in the blade tip, hardened, galvanized
- Max. torque
5.0 - 14.0 Nm
- Standards
In accordance with EN ISO 6789
- EN standard
EN ISO 6789
EN 26789
ASME B107.14M
- Product type
Torque screwdriver
Variants(All information is without VAT, plus shipping costs)
Product type
Wiha 29233 Workshop Torque screwdriver 5 - 14 Nm DIN EN ISO 6789, DIN EN 26789
This article
Torque screwdriver
Minimum order quantity: 1
Multiple: 1
€ 151.25*
Wiha 29234 Workshop Torque screwdriver set 12-piece 5 - 14 Nm DIN EN ISO 6789, DIN EN 26789
Torque screwdriver set
Minimum order quantity: 1
Multiple: 1
€ 184.87*
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 803999 Wiha 29233 Workshop Torque screwdriver 5 - 14 Nm DIN EN ISO 6789, DIN EN 26789
Description
Driving side: DIN 3126, ISO 1173, Form D 6.3 For screw joints of all kinds in trade and industry. For controlled screwing at a predefined torque., in combination with a WIHA torque 6-mm changing blade. For controlled screwing with nuts at a predefined torque. For controlled screwing with bits at a predefined torque. Extra: supplied in a practical plastic box, incl. factory testing protocol. Accuracy: ±6%, traceable to national normal. Handle: Made of tough cellulose acetate. numerical torque value display in window scale. Torque can be set continuously with adjustment tool torque-setter (included in the delivery). Comfortable Cross-handle with soft zones for optimum transmission of torque. Click signal upon reaching the set torque value. Sleeve: Bit-Schnellwechselhalter for Wiha cross-grip torque tools. Enables a particularly fast bit change. Blade: octagonal profile with hole in the blade tip, through-hardened, galvanised. High-quality chromium-vanadium-molybdenum steel, through-hardened, matt chrome-plated. Head: nickel-plated, spring-loaded ball. EN ISO 6789, BS EN 26789, ASME B107.14M Bits: High quality chrome-vanadium steel, pierced hardened, bronzed.
Features
- Meets your requirements: Variable adjustable torque covers a wide range of applications
- Increases your efficiency: The right torque protects you from material damage and rework.
- Simplifies the handling: Effortless and comfortable transfer of high torque thanks to cross-grip with comfortable grip.
- For controlled screwing at a predefined torque., in combination with a Wiha torque of 6 mm reversing blade.
- Extra: Supplied in a practical plastic box, including factory test protocol.
- Accuracy: ±6%, traceable to national normal.
- Handle: Comfortable cross-grip with soft zones for optimum transfer of torque.
- Handle: Numeric torque value display in window scale.
- Handle: Torque can be adjusted continuously with adjustment tool torque-setter (included in the delivery).
- Handle: Click signal when set torque value is reached.
- Handle: Compatible with all 2899 series blades.
- DIN EN ISO 6789
Scope of delivery
- Torque screwdriver with cross-grip TorqueVario® S T 5-14 Nm variable adjustable torque limit 5 - 14 (29233)
Hints
This text is machine translated.
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
