Number
Total (1 m = € 0.78)
€ 77.99
incl. VAT
Only 4 Set(s) available
Technical specifications
- Product type
Jumper wire
- No. of leads
2 x
- Content
100 m
- Cross section (each core)
0.8 mm²
- Insulation material
PVC
- Cable features
Tin-plated
- Cable type
Yv
- Manufacturer part #
YV 2x0,8 sw/w
- Max. length sold by the metre
100 m
- Sold per metre
Yes
- Cross section
2 x 0.8 mm²
- Min. temperature range (flexible installation)
-5 °C
- Min. temperature range (fixed installation)
-30 °C
- Type
YV 2x0,8 sw/w
- Standards
Verband Deutscher Elektrotechniker e.V. (VDE)
0.8 mm²
2.8 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2984910 YV 2x0,8 sw/w Jumper wire Yv 2 x 0.8 mm² 100 m
Description
Switch/shunting wire made of a tin-plated conductor, with PVC insulation, according to DIN VDE 0472-804 test type A, solid Cu conductors, rated voltage 900 V, temperature range moving -5°C to + 70°C, temperature range laid fixed -30°C to + 70°C, PVC self-extinguishing and flame-resistant, for use in communications technology, in telecommunications systems and in all areas of general wiring technology, Not applicable outside of appliances, not bending or turning!
This text is machine translated.
This text is machine translated.
