13.S2.8.230.B000 Finder YESLY 2-channel Blinds actuator
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 78.98 / piece)
€ 78.98
plus VAT.
Finder YESLY blinds actuator 2-channel, flush-mounted
Highlights & Details
- Control of blinds and shutters
- High load capacity
- Ideal for the YESLY-System
Technical specifications
- Permissible load 2 x 1380 VA (AC1), 2 x 300 VA (AC15), 2 x 200 W (AC3)
- Nominal voltage: 230 V/AC
- Surrounding temperature -10 to +50 °C
- Series
Finder YESLY
- Transfer Standard (Smart Home)
Bluetooth Low Energy
IP20
- Power supply (LOV)
mains-powered
- Operating voltage
230 V AC
- Data transfer (Smart Home)
Wireless
- Channels
2
- Frequency
2.4 GHz
10 m
- Mounting type
Flush mount
- Width
43 mm
- Height
21.9 mm
- Depth
44.1 mm
- Dim
(W x H x D) 43 x 21.9 x 44.1 mm
n.rel.
- Hub
Not required, optional for remote access
- Weight
45 g
- UKCA
yes
- Product type
Blinds actuator
Documents & Downloads
Datasheet
Datasheet 2141275 13.S2.8.230.B000 Finder YESLY 2-channel Blinds actuator
User & Safety Instructions
User & Safety Instructions 2141275 13.S2.8.230.B000 Finder YESLY 2-channel Blinds actuator
Information
Information 2141275 13.S2.8.230.B000 Finder YESLY 2-channel Blinds actuator
Description
The blinds actor 13.22 is specially designed for roller shutters and blinds control via Finder YESLY or conventional keys and can be installed invisibly in a flush-mounted socket Electric shutters or blinds can then be smart about the different YESLY-radio button, the smartphone or tablet. Furthermore, there are pre-programd scenarios possible, in order to simulate a desired atmosphere in combination with other components. Of course, you can still wired button directly to the key inputs can be connected to existing systems can be used to keep and extend. The programming and integration into the YESLY-System is done with the help of the Finder Toolbox+ app for iOS and Android available free of charge. The Communication is based on the sophisticated Bluetooth® Low Energy Technology and is also 128-bit encrypted.
This text is machine translated.
This text is machine translated.
Features
- Operational reliability through 128-bit encryption
- can also be controlled by buttons.
Scope of delivery
- Shutter actuator
- User manual.
