Name: Absima CR4S Pistol grip RC 2,4 GHz No. of channels: 4
Brand: Absima
SKU: 2536522
Availability: InStock

A black remote control with a large handle, side steering wheel and digital display showing 'Absima'. Suitable for RC vehicles.

A black radio remote control with a pistol grip, control buttons on top and an antenna. Suitable for model vehicles.

A black remote control device with multiple buttons and a rotary dial on the right side, used for controlling models.

A detailed close-up of a black, ergonomic remote control device with visible buttons and levers on the side.

Two black remote controls for RC vehicles with an ergonomic grip and rotary dial, presented on a white surface.

Grip of a remote-controlled device with two white buttons, a switch, and a fan wheel used for control purposes.

A small, rectangular electronic device with multiple ports and a long cable. It could be a sensor or a control unit.

1/8

Fast track dispatch on Fri 16 Oct

10 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 43.99 / piece)

€ 43.99

incl. VAT

Only 10 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

4-channel remote control "CR4S" 2.4GHz incl. receiver R4WP-Micro

4 channelsBeginner modeSecure 2.4 GHz transmission technologyIncludes 4-channel receiver

Technical specifications

Protocol: ANTDistance: Up to 150 m.Low V warning: To 4.2V (NiMH only)Use only LiPo battery with built-in Low V protection functionInternal antennaTemperature range: -10 to +60 °C.Remote control dimensions (LxWxH): 118x73x145 mmWeight of remote control: Approx. 130 g4 channels receiverExternal with antenna pipeWaterproof receiverOperating voltage receiver 3.5-8.4VReceiver with fail-safe in connection with remote controlReceiver dimensions (LxWxH): 30.2x18 x 13 mmReceiver weight 5 g

Product type: Pistol grip RC

Frequency: 2,4 GHz

Channels: 4

Weight: 130 g

Factory colour: Black

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2536522 Absima CR4S Pistol grip RC 2,4 GHz No. of channels: 4

Description

The "CR4S" is a 4-channel remote control including receiver, which uses the latest AFHDS 2.4GHz "ANT" frequency jump technology from ABSIMA. Light and compact design, as well as comfortable and ergonomically shaped. Moreover, the remote control has a "beginner mode" and is therefore also suitable for pilots with little experience and also children. The receiver included in the delivery is very compact in design with a size of 30.2x18 x 13 mm and fits in almost every receiver box.

This text is machine translated.

Features

The transmitter has 4 channels which are divided as follows) - CH1: Steering wheel / CH2: Throttle (trigger) / CH3: 3-position toggle switch / CH4: Push buttonReverse function (REV): With this function you can set the direction of rotation of the steering servo/motorTrim (TRIM): Sets the straight run and the throttle neutral positionDual rate function (D/R): By pressing the rotary controls, the steering angle or the motor rotation power can be increased/reducedFail-safe function: This function specifies what the receiver should pass on if the signal to the transmitter has been lost (e.g. emergency braking)Beginner mode: This function is intended for beginners. In this mode, the engine power is automatically reduced to 50%

Scope of delivery

CR4S remote control
R4WP micro receiver
Antenna pipe
User manual

Description

Features

The transmitter has 4 channels which are divided as follows) - CH1: Steering wheel / CH2: Throttle (trigger) / CH3: 3-position toggle switch / CH4: Push buttonReverse function (REV): With this function you can set the direction of rotation of the steering servo/motorTrim (TRIM): Sets the straight run and the throttle neutral positionDual rate function (D/R): By pressing the rotary controls, the steering angle or the motor rotation power can be increased/reducedFail-safe function: This function specifies what the receiver should pass on if the signal to the transmitter has been lost (e.g. emergency braking)Beginner mode: This function is intended for beginners. In this mode, the engine power is automatically reduced to 50%
