Amphenol C016 10I012 003 2 Cable Connector Straight C16-3 Nominal current (details): 3 x 21A ,9 x 11 A
EAN:
Part number:
Item no:
Product type
Bullet connector
Connector type
Plug, straight
Total no. of pins
12 + PE
Connection
Crimp
Content
1 pc(s)
Datasheet (PDF)
Number
Total (€ 13.44 / piece)
€ 13.44
plus VAT.
Only 7 Piece(s) available
Highlights & Details
Amphenol C016 10I012 003 2 Cable Connector Straight C16-3 Nominal current (details): 3 x 21A ,9 x 11 A
- Housing size 2
Technical specifications
- Type
C016 10I012 003 2
- Product type
Bullet connector
- Connector type
Plug, straight
- Total no. of pins
12 + PE
- Connection
Crimp
- Content
1 pc(s)
- Nominal current
21 A
- Nominal current - rounded value
21 A
- Leading contact (PE)
Yes
- Nominal voltage
500 V
- Contact material
Silver plated
- Case material
Polyamide 6.6
- Connection angle
180°
- Manufacturer part #
C016 10I012 003 2
- Number of pins
12
- max. cross section
2.5 mm²
- Cross-section range
2.5 mm² (max)
IP65
- Series
C016
- Type
straight
- Resistance
≤ 5 mΩ
- Nominal voltage (details)
3 x 500V, 9 x 300 V
- Nominal current (details)
3 x 21A ,9 x 11 A
- Cross section
0.14 -2.5 mm²
- Connection
Crimp
- Temperature range
-40 - +125 °C
Documents & Downloads
Datasheet
Datasheet 740897 Amphenol C016 10I012 003 2 Cable Connector Straight C16-3 Nominal current (details): 3 x 21A ,9 x 11 A
User & Safety Instructions
User & Safety Instructions 740897 Amphenol C016 10I012 003 2 Cable Connector Straight C16-3 Nominal current (details): 3 x 21A ,9 x 11 A
Information
Information 740897 Amphenol C016 10I012 003 2 Cable Connector Straight C16-3 Nominal current (details): 3 x 21A ,9 x 11 A
Description
The series meets the high standards of the industrial technology under very harsh environmental conditions with respect to structure and concept. A selection of crimp contacts for processing with crimping tools and machines enables a rational processing with qualitative, technical and economical advantages. The series is applicable in mechanical engineering plants, measurement- and control technology, process engineering and electro medical equipment and guarantees a vibration free connection through a bayonet-type locking mechanism with latching in final position. The inner cable strain relief clamp prevents the cable from strain relief.
Hints
Supplied without crimp contact
