ATEN CS64US 4 ports KVM changeover switch VGA USB 2048 x 1536 Pixel
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 43.69 / piece)
€
Only 9 Piece(s) available
Highlights & Details
Aten CS64US KVM switch
- A USB console controls four computers with USB ports
- Maximum resolution: up to 2048 x 1536 pixels
- No external power supply required
Technical specifications
- Product type
KVM changeover switch
- No. of switchable PCs
4
- Video via
VGA
- Video resolution
2048 x 1536 Pixel
- Controller
USB
- Audio headphones
No
- Audio microphone
Yes
- No. of USB 2.0 ports
2 x
- Stackable
No
- Rack mount option
No
- Switch function
Hot key
- Power supply (LOV)
not required
- Factory colour
Black
- Weight
0.8 kg
- Length
25 mm
- Width
109 mm
- Height
97 mm
- Port
4 ports
- Dim
(L x W x H) 25 x 109 x 97 mm
Documents & Downloads
Datasheet
Datasheet 401737 ATEN CS64US 4 ports KVM changeover switch VGA USB 2048 x 1536 Pixel
User & Safety Instructions
User & Safety Instructions 401737 ATEN CS64US 4 ports KVM changeover switch VGA USB 2048 x 1536 Pixel
Description
Features.
- One USB console controls four USB computers- Compact design, built-in 0. 9/1. 2 m cables- Hotkey selection for OS and keyboard language- Computer Selection via hotkey and USB mouse- Multiplatform support - Windows, Linux, Mac, Sun- Video DynaSync ™ - exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports- USB mouse port can be used for USB 1. 1 hub and USB 1. 1 peripheral sharing- Supports multifunction and wireless keyboards and mice- All-in-one design- With speaker support- Superior video quality – up to 2048 x 1536; DDC2B- Auto Scan function to monitor computer operation- Non-powered- Sun/Mac keyboard support and emulation*- Firmware upgradable* 1. PC keyboard combinations emulate Sun/Mac keyboards* 2. Sun/Mac keyboards only work with their own computersPackage Contents.
- 1x 4-Port CS64US USB KVM Switch- 2x Hotkey Stickers- 1x User Instructions
- One USB console controls four USB computers- Compact design, built-in 0. 9/1. 2 m cables- Hotkey selection for OS and keyboard language- Computer Selection via hotkey and USB mouse- Multiplatform support - Windows, Linux, Mac, Sun- Video DynaSync ™ - exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports- USB mouse port can be used for USB 1. 1 hub and USB 1. 1 peripheral sharing- Supports multifunction and wireless keyboards and mice- All-in-one design- With speaker support- Superior video quality – up to 2048 x 1536; DDC2B- Auto Scan function to monitor computer operation- Non-powered- Sun/Mac keyboard support and emulation*- Firmware upgradable* 1. PC keyboard combinations emulate Sun/Mac keyboards* 2. Sun/Mac keyboards only work with their own computersPackage Contents.
- 1x 4-Port CS64US USB KVM Switch- 2x Hotkey Stickers- 1x User Instructions
Features
- Hotkey selection for the operating system and the keyboard language
- Sound transmission
- Video Dyna Sync™ exclusive technology of calls for avoiding display problems at restart and optimization of the resolution at the port switching
- Compact design, built-in cable (0.9/1.2 m)
- Multi-platform compatible with Windows, Linux, Mac and Sun
- The USB mouse port can also be used for a USB hub or shared USB peripheral devices can be used
- Supports USB multimedia keyboards and multi-functional mice
- All-in-One-Design
- Automatic port switch-over for the monitoring of the computer
- Computer selection via hotkeys
- Supports and emulates Sun/Mac-Tastaturen
- Firmware update possible
Scope of delivery
- USB KVM switch
- 2 x hotkey button sticker
- User manual.
System requirements
- Windows® 2000/XP
- Windows Vista™
- LINUX
- Mac
- Sun
- FreeBSD.
