binder 09 0037 00 05 Circular Connector With Screw Lock Nominal current (details): 10 A Pins: 5

A black and silver five-pin DIN plug is shown.
'Diagram of a 5-pin DIN plug, numbered connections from 1 to 5 within a circle with orientation marking.'
1/2
Image similar
Product type
Bullet connector
Connector type
Plug, straight
Total no. of pins
5
Connection
Soldering
Content
1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
74 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 44.99 / piece)
€ 44.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

  • Grommet (kink inhibitor): PVC
  • Blade: silver-plated
  • Nickel-plated pins
Type

09 0037 00 05

Product type

Bullet connector

Connector type

Plug, straight

Total no. of pins

5

Connection

Soldering

Content

1 pc(s)

Max. temperature

+130 °C

Nominal current

10 A

Min. temperature

-20 °C

Nominal current - rounded value

10 A

Seal

Screws

Nominal voltage

250 V

Contact material

Silver plated

Cable Ø (max.)

8 mm

Cable Ø up to

5 mm

Case material

Aluminium

16

Connection angle

180°

Manufacturer part #

09-0037-00-05

Cable Ø range

5 - 8 mm

Number of pins

5

max. cross section

1.5 mm²

Cross-section range

1.5 mm² (max)

IP40

Material (details)

Aluminium

Type

Cable connector

Nominal voltage (details)

250 V AC

Nominal current (details)

10 A

Cross section

max. 1.5 mm²

Pins

5

Connection

Soldering

Cable diameter

5-8 mm

Temperature range

-40 - +85 °C

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 738956 binder 09 0037 00 05 Circular Connector With Screw Lock Nominal current (details): 10 A Pins: 5

User & Safety Instructions

User & Safety Instructions 738956 binder 09 0037 00 05 Circular Connector With Screw Lock Nominal current (details): 10 A Pins: 5

Description

· Connector with screw locking
· In-built cable strain relief
· Transparent cable bend protection
