Name: Busch-Jaeger Studio white (similar to RAL 9016) 2CKA006220A0068 1 pc(s)
Brand: Busch-Jaeger
SKU: 3834124

A dark rectangular notebook or planner with rounded corners, shown closed on a white background, with a small clapperboard-style icon and green square on the cover.

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Rocker 2-f re symbol scene anthracite 6233-22-81

Busch & Jaeger Switch Product Range

Technical specifications

Usage: For data-connection casing
Mounting method: Fixing with screw
Material quality: Thermoplastic
Halogen-free: Yes
Surface protection: Painted
Design of surface: Matt
Antibacterial treatment: No.
Mounting type: Flush-mounted
Transparent: No.
Min Depth of the device socket 32 mm
Composition: Central plate for intermediate ring
Device width 63 mm
Device height 63 mm
Device depth 31.8 mm
Bearing ring: No.
With dust protection: No.
With hinged cover: No.
Outlet direction: Straight
Labelling field: Without labeling field
With imprint: No.
Number of modules (for modular design): 1
With sockets/couplings: No.
Suitable for number of sockets/couplings: 1
With strain relief: No.
Shielded sockets: No.
Shielded housing: No.
Connector strip: No.
With illumination: No.

Type: Rocker 2-f re symbol scene anthracite 6233-22-81

Product type: Toggle

Factory colour: Studio white (similar to RAL 9016)

Content: 1 pc(s)

Similar RAL: 9016

Material: Plastic

Mounting type: Flush mount

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3834124 Busch-Jaeger Studio white (similar to RAL 9016) 2CKA006220A0068 1 pc(s)

Description

As a cover for Busch-free@home® sensor unit, KNX button coupling or control element Flex, 2-fold. Design line: Platform 63, future® linear, Busch-aXcent®, karat®, Busch-dynasty® design line Variant: Busch-aXcent®, Busch-aXcent® pure product line: KNX, Busch-free@home®, Busch-Flextronics®, Busch-Flextronics® Wireless, Busch-free@home® Wireless

This text is machine translated.
