CONTA-CLIP KDS-DE 12-13 BK Sealing with strain relief Terminal Ø (max.) 13 mm Thermoplastic elastomer Black 10 pc(s)

Rectangular rubber door stop with a round, ribbed hole in the centre, suitable for door stop pins or holders.
Product type
Sealing
Features
with strain relief
Material
Thermoplastic elastomer
Clamp Ø
12 mm
Terminal Ø (max.)
13 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Thu 12 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 10 pc(s))
Total (€ 2.60 / piece)
€ 25.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Sealing element

Our service for you

Technical specifications

  • Number of lines: 1Flammability class UL 94: HBDIN: Strain relief according to DIN EN 62444for cable diameter up to 13 mm.Cable diameter min.: 12 mmMounting type: InsertRAL 9005UV-stabilized: YesStrain relief : Yes
Product type

Sealing

Features

with strain relief

Factory colour

Black

Material

Thermoplastic elastomer

Length

20.3 mm

Width

20.3 mm

Height

17.7 mm

Dim

(L x W x H) 20.3 x 20.3 x 17.7 mm

Clamp Ø

12 mm

Terminal Ø (max.)

13 mm

Min. temperature

-40 °C

Max. temperature

+120 °C

IP66

Halogen-free

Yes

Content

10 pc(s)

Manufacturer part #

28532.4

Type

KDS-DE 12-13 BK

RoHS-compliant

Yes

Material properties

silicone-free

Documents & Downloads

Datasheet

Datasheet 2617422 CONTA-CLIP KDS-DE 12-13 BK Sealing with strain relief Terminal Ø (max.) 13 mm Thermoplastic elastomer Black 10 pc(s)

User & Safety Instructions

User & Safety Instructions 2617422 CONTA-CLIP KDS-DE 12-13 BK Sealing with strain relief Terminal Ø (max.) 13 mm Thermoplastic elastomer Black 10 pc(s)

Description

Sealing element, mounting type: Insert, length x width: 20.3 mm, cable diameter max.: 13 mm, IP66, color: Black

This text is machine translated.
