CONTA-CLIP KDS-Set 8/16 BK Cable grommet waterproof Polyamide 6.6 Black 1 pc(s)

Black rectangular frame with four mounting holes and two transverse crossbars in the centre.
Product type
Cable grommet
Material
Polyamide 6.6
Features
waterproof
Factory colour
Black
Bore diameter
5.5 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Thu 12 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 45.99 / piece)
€ 45.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Cable bushing set

Our service for you

Technical specifications

  • Number of screw holes: 4Type of seal: Flexible sealing foam and foamBuilding height 19.6 mmWidth of wall cut-out: 46 mmFlammability class UL 94: V-0Sealing material: Polyurethane baseTightening torque of the mounting bolts: 3 NmDiameter of screw holes 5.5 mmLength of wall cut-out: 91 mmMounting type: ScrewsRAL 9005
Product type

Cable grommet

Features

waterproof

Factory colour

Black

Bore diameter

5.5 mm

Material

Polyamide 6.6

Length

126 mm

Width

70 mm

Height

19.6 mm

Min. temperature

-40 °C

Max. temperature

+120 °C

IP66

Weight

0.0670 kg

Halogen-free

Yes

Content

1 pc(s)

Dim

(L x W x H) 126 x 70 x 19.6 mm

RoHS-compliant

Yes

Manufacturer part #

28604.4

Type

KDS-Set 8/16 BK

Material properties

fibreglass-reinforced

silicone-free

Mounting hole

M5

UKCA

not relevant

Documents & Downloads

Datasheet

Datasheet 2617537 CONTA-CLIP KDS-Set 8/16 BK Cable grommet waterproof Polyamide 6.6 Black 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2617537 CONTA-CLIP KDS-Set 8/16 BK Cable grommet waterproof Polyamide 6.6 Black 1 pc(s)

Description

Cable gland set, IP66, consisting of: 1 x KDS-SR 8/16, 1 x KDS-Inlay 1, 2 x KDS-Inlay 4
