DC/DC-CONVERTER, 150 W, 72 V/15 V. TracoPower TEP 150-7213WI 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Total (€ 239.50 / piece)
€
Highlights & Details
DC/DC-CONVERTER, 150 W, 72 V/15 V.
- Shielded metal housing with screw terminalsCompact dimensions 98 mm x 52 mm x 34 mmUltra wide 4:1 input rangesHigh electrical efficienyConstant current at 100% load for battery chargingOver heating protectionOperating temperature range -40°C to +75°C.Reverse polarity protectionUndervoltage switch-off at the inputE/A-INSULATION 2250 VDCSimple chassis and wall mounting
Technical specifications
- Input voltage 43-160 V
- Output voltage 15 V
- Output current: 10 A
- Power: 150 watts
- Efficiency 86 %
- Setting range for the output voltage +20% (with ext. Resistance)
- Control deviations: Input variation: Max. 0.2 %, load variation (0-100%): Max. 0.4 %
- Remaining ripple (20 MHz bandwidth) 100 mV pk-pk
- Short-circuit protection: Continuous, automatic Restart
- Operating temperature range:-40°C to +75°C, power reduction: See data sheet
- E/a-insulation 2250 VDC (60 s)
- Safety standards UL/cUL 60950-1, IEC/EN 60950-1.
- Product type
- Output current (max.) - rounded
- Output voltage (max.)
15 V DC
- Dim
(L x W x H) 34.00 x 98.00 x 52.00 mm
- Weight
300 g
- Content
1 pc(s)
- Width
98.00 mm
- Height
52.00 mm
- Length
34.00 mm
- RoHS-compliant
- Type
TEP 150-7213WI
Documents & Downloads
Datasheet
Datasheet 2789981 DC/DC-CONVERTER, 150 W, 72 V/15 V. TracoPower TEP 150-7213WI 1 pc(s)
Datasheet 2789981 DC/DC-CONVERTER, 150 W, 72 V/15 V. TracoPower TEP 150-7213WI 1 pc(s)
Warranty Terms
Warranty Terms 2789981 DC/DC-CONVERTER, 150 W, 72 V/15 V. TracoPower TEP 150-7213WI 1 pc(s)
Description
The TEP-150WI series offers very powerful, insulated DC/DC-converters with an ultra-wide 4:1 input range in a robust, shielded metallic casing. These converters are suitable for a large range of applications, specially designed for industrial applications. The modules can be installed very easily in the chassis or wall mounting. The very high degree of efficiency permits a working temperature range of up to +50 °C with natural convection cooling without a reduction of power. Additional features include output voltage with constant power characteristic for battery applications.
