1/2
Dehner Elektronik LED 12V200W-MM-EU LED transformer, LED driver Constant voltage 200 W 15 A 12 V DC Approved for use on
EAN:
Part number:
Item no:
Number
Total (€ 71.99 / piece)
€ 71.99
incl. VAT
Only 3 Piece(s) available
Highlights & Details
Dehner Elektronik LED 12V200W-MM-EU
- Constant voltage
- 12 V DC
- 15 A
Technical specifications
- Product type
LED transformer
- Type
Constant voltage
- Operating current
15 A
- Dim
(L x W x H) 195 x 65 x 35 mm
- Factory colour
White
- Output voltage (max.)
12 V DC
- Output voltage (min.)
12 V DC
- Test mark
MM; SELV
- Max. output current
15 A
- Output current (max.) - rounded
15 A
- Protection class
IP20
- LED driver features
Approved for use on furniture
IP20
- Connection
Screw terminal
- Max. power
200 W
- No. of outputs
1 x
- No. of inputs
1 x
- Type
Switched PSU
- Output current (min.)
15 A
- Input voltage (max.)
240 V AC
- Min. input voltage
200 V AC
- Weight
460 g
- Power (min.)
200 W
- Power range
200 up to 200 W
- Width
65 mm
- Height
35 mm
- Length
195 mm
- Max. temperature
45 °C
- Min. temperature
-20 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2162999 Dehner Elektronik LED 12V200W-MM-EU LED transformer, LED driver Constant voltage 200 W 15 A 12 V DC Approved for use on
Warranty Terms
Warranty Terms 2162999 Dehner Elektronik LED 12V200W-MM-EU LED transformer, LED driver Constant voltage 200 W 15 A 12 V DC Approved for use on
Description
LED power supply / LED driver, 200 Watt, corresponds to the safety standard for lighting, suitable for furniture installation.
Power supply specially designed for LED lighting. The constant voltage source is suitable for all LED lighting, in which a control electronics is connected upstream e.g. for brightness control.
This text is machine translated.
Power supply specially designed for LED lighting. The constant voltage source is suitable for all LED lighting, in which a control electronics is connected upstream e.g. for brightness control.
This text is machine translated.
Scope of delivery
- User manual
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
