Image similar
1/2
Image similar
Diotec B80C5000A Diode bridge SIL 4 160 V 5 A 1-phase
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 1.92
10
7% = € 0.14
€ 1.78
25
10% = € 0.20
€ 1.72
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 1.92 / piece)
€
Technical specifications
- Type
B80C5000A
- Enclosure
SIL 4
- Manufacturer
Diotec
- Manuf. code
DIO
- Configuration (diode)
1-phase
- U(RRM)
160 V
- Forward current I(F)
5 A
- I(FSM) 50Hz
150 A
- I(FSM) 60Hz
165 A
- Reverse leakage current I(r)
5 µA
- Reverse leakage current I(r) reference
160 V
- Operating temperature (min.)
-50 °C
- Operating temperature (max.)
+150 °C
- Mounting type
Through-hole
- RoHS-compliant
Yes
- Nominal current (details)
3.3 A (5 A)
- Voltage
80 V
- Product type
Diode bridge
Documents & Downloads
Datasheet
Datasheet 501930 Diotec B80C5000A Diode bridge SIL 4 160 V 5 A 1-phase
Description
Rectifiers from leading manufacturers. Full details free to download from our comprehensive product documents library.
Hints
Rated current (free-standing) = 3.3 A/ rated current (chassis assembly) = 5 A
