'Two black semiconductor components in a TO-220AC package, one on top, one on bottom, each with three connecting pins.'

'Two black semiconductor components in a TO-220AC package, one on top, one on bottom, each with three connecting pins.'

Image similar

Product type

Rectifier

Enclosure

TO 220AC

Forward current I(F)

8 A

Reverse voltage U(R)

600 V

Forward voltage U(F)

1.75 V

Datasheet (PDF)

Diotec

Dispatches on Thu 22 Oct

970 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Minimum order quantity: 30

Total (€ 0.72092 / piece)

€ 21.63

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Type wire-leadCasing TO-220AC.Periodic Peak Reverse Voltage - VRRM 600 VContinuous current - IFAV 8.00 AJunction temperature - Tjmax 150 °CReverse delay time - trr: 35 nsSurge current - IFSM 112.00 AForward voltage - VF 1.75 VIF 8.00 AReverse current - IR 5,000 µAVR 600 VLock layer capacity - CJ: PFVR V

Type: UFT800J

Product type: Rectifier

Enclosure: TO 220AC

Manufacturer: Diotec

Forward current I(F): 8 A

Reverse voltage U(R): 600 V

Forward voltage U(F): 1.75 V

Reverse leakage current I(r): 5 µA

Operating temperature (max.): 150 °C

Mounting type: Through-hole mounting

I(FSM) 50Hz: 112 A

Reverse recovery time T(rr): 35 ns

RoHS-compliant: Yes

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2808859 Diotec Rectifier UFT800J TO 220AC 600 V 8 A

User & Safety Instructions

User & Safety Instructions 2808859 Diotec Rectifier UFT800J TO 220AC 600 V 8 A
