Name: Ehmann 0206x01053301 Surge protection power strip 5x Grey PG connector 1 pc(s)
Brand: Ehmann
SKU: 623504
Availability: InStock

Highlights & Details

Surge protection socket strip

With acoustic signal tone and visual signal light
With child protection

Technical specifications

1 illuminated, 2-pole switch

Product type: Surge protection power strip

Light bulb features: Surge protection
incl. switch
Child safety

Outlets: 5

Cable length: 1.50 m

Used at: Indoors

Mounting type: Fixing holes

Material: Plastic

Function display: visual
acoustic

Leakage current: 6.5 kA

Type: With audible function display

Plug type: PG connector

Cable standard: H05VV-F 3G 1,5 mm²

Operating voltage: 230 V AC

Power rating: 3600 W

Factory colour: Grey

Length: 462 mm

Width: 75 mm

Height: 54 mm

Cable type: H05VV-F 3 G 1.5 mm²

Nominal voltage (details): 230 V AC

Nominal current (details): 16 A

Operating voltage: 230 V/50 Hz

Documents & Downloads

Datasheet

Datasheet 623504 Ehmann 0206x01053301 Surge protection power strip 5x Grey PG connector 1 pc(s)

User & Safety Instructions

User & Safety Instructions 623504 Ehmann 0206x01053301 Surge protection power strip 5x Grey PG connector 1 pc(s)

Description

When the surge protection has been triggered, the "active protection" light on the front goes out and an audible signal is given. The connected devices continue to operate even when the surge protection is inactive. To regain the protection function, renew the built-in fine-wire fuse (T6.3 A/250 V). Separate the connected two-pole loads above the in-built illuminated switch from the mains.

Features

Response time <25 ns
Fine fuse T6,3 A/250 V

Scope of delivery

Replacement fuse included.

Description

When the surge protection has been triggered, the "active protection" light on the front goes out and an audible signal is given. The connected devices continue to operate even when the surge protection is inactive. To regain the protection function, renew the built-in fine-wire fuse (T6.3 A/250 V). Separate the connected two-pole loads above the in-built illuminated switch from the mains.
