Name: Escha 8012651 Sensor/actuator splitter/adapter M8 T splitter No. of pins (RJ): 4, 3 1 pc(s)
Brand: Escha
SKU: 3553359
Availability: InStock

Technical specifications

Insulation resistance ≥108 Ω
Material seal (bush): FPM/FKM
Material grip body: Plastic, TPU, BK
Mechanical lifespan >100 mating cycles
IEC 61076-2-101/-104
Protection type (mounted): IP65, IP67, IP68
Ambient temperature: -30°C...+90°C
Pollution level 3
Rated voltage (side A | side B): 250V
Material contacts (side A | side B): Metal, CuZn, gold-plated
Material contact carrier (page A | page B): Plastic, TPU, BK
Material over-throw (side A | side B): Metal, CuZn, nickel-plated
Current rating per pin (at 40°C) (side A | side B): 4 A.
Output (side A | side B): Socket, M12;plug, M12
Coding (page A | page B): A.
Number of pins (page A | page B): 4;3

Type: FKM4-2FSM3/S89

Product type: Sensor/actuator splitter/adapter

Connector type: T splitter

Connector standard: RJ45

Connection side A: M12 socket, straight

Connection side B: M12 plug, straight

No. of pins: 4
3

Nominal voltage: 250 V

Nominal current: 4 A

Nominal current - rounded value: 4 A

Connection: M12 socket

Thread type connection side: M8

Thread type (wiring and installation): M8

Coding: A

Contact material: CuZn

Contact surface: Gold plated

Min. temperature: -30 °C

Max. temperature: 90 °C

Manufacturer part #: 8012651

Content: 1 pc(s)

Documents & Downloads

Datasheet

Datasheet 3553359 Escha 8012651 Sensor/actuator splitter/adapter M8 T splitter No. of pins (RJ): 4, 3 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3553359 Escha 8012651 Sensor/actuator splitter/adapter M8 T splitter No. of pins (RJ): 4, 3 1 pc(s)

Description

Escha standard connection technology stands for variety, quality and reliability in the protection classes IP67, IP68 and IP69. Thanks to different designs, codes and a variety of cable qualities, you will find the right solution for every application. Whether M8, M12 or M23 round connectors, RJ45 or solenoid connectors – all products come in many cable lengths. Practical T and Y-distributor, panel-mounted plug, adapter and I/O-modules enable a flexible wiring structure.
