FESTO 536966 MS4-FRM-1/4-I Splitter Compressed air, Inert gas Max. operating pressure 10 bar
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 53.99 / piece)
€ 53.99
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
Splitter MS4-FRM-1/4-I
Technical specifications
- Product type
Splitter
- Type
MS4-FRM-1/4-I
- Min. operating pressure
0 bar
- Max. operating pressure
10 bar
- Operating medium
Compressed air
Inert gas
- Device temperature (max.)
+60 °C
- Min. device temperature
-10 °C
- Manufacturer part #
536966
- Material (details)
Diecast aluminium
- Type
Branch module MS4 FRM-1/4-I with built-in check function, flow direction from left to right. Installation position=any, constructive design = (* branch module, * with non-return function)
- Operating medium
According to ISO 8573-1:2010 compressed air [7:4:4],, inert gases
- Max. flow
1750 l/min
- Connection
G1/4"
- Weight
160 g
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1934932 FESTO 536966 MS4-FRM-1/4-I Splitter Compressed air, Inert gas Max. operating pressure 10 bar
User & Safety Instructions
User & Safety Instructions 1934932 FESTO 536966 MS4-FRM-1/4-I Splitter Compressed air, Inert gas Max. operating pressure 10 bar
