FESTO Linear actuator ESBF-LS-40-400-3P 8022588 Stroke length 400 mm 1 pc(s)
EAN:
Part number:
Item no:
Speed (max.)
0.15 m/s
Stroke length
400 mm
Product type
Linear actuator
Manufacturer part #
8022588
Type
ESBF-LS-40-400-3P
Datasheet (PDF)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 1,189.00 / piece)
€ 1,189.00
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
Linear actuator ESBF-LS-40-400-3P
Technical specifications
- Electric cylinder ESBF-LS -40-400-3P with sliding screw drive, electrically driven spindle the rotary motion of the motor into a linear movement of the piston rod. Working stroke=400mm, size = 40, Hub = 400 mm, Piston Rod Thread = M12 x 1.25, reversing clearance = 100 µm, material cylinder tube = aluminum wrought alloy
- Manufacturer part #
8022588
- Type
ESBF-LS-40-400-3P
IP40
- Size
40
- Speed (max.)
0.15 m/s
- Stroke length
400 mm
- Max. ambient temperature
60 °C
- Min. ambient temperature
0 °C
- UKCA
not relevant
- Product type
Linear actuator
Documents & Downloads
Datasheet
Datasheet 1937820 FESTO Linear actuator ESBF-LS-40-400-3P 8022588 Stroke length 400 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1937820 FESTO Linear actuator ESBF-LS-40-400-3P 8022588 Stroke length 400 mm 1 pc(s)
What kind of Electric Cylinders are you looking for?
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
