Name: FESTO Proximity sensor Inductive SME-8M-ZS-24V-K-2,5-OE 543872 T groove Two-wire
Brand: FESTO
SKU: 1943937
Availability: InStock

Electrical wiring loom with multiple wrapped sections and connectors, designed to facilitate connections between devices and systems.

Product type

Proximity sensor

Max. operating voltage

30 V AC

Outputs

Two-wire

Model

Inductive

Connector

Cable

Datasheet (PDF)

4 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 39.99 / piece)

€ 39.99

incl. VAT

Only 4 Piece(s) available

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Proximity switch SME-8M-ZS-24 V-K-2.5-OE

Technical specifications

Proximity switch electrically, with reed contact, two-wire design, for drives with T-slot, assembly from above, with cable
Weight: 26.3 g
Max. output current 80 mA
Mounting type: screwed
Max. circuit breaking capacity 2.4 W

Product type: Proximity sensor

Type: SME-8M-ZS-24V-K-2,5-OE

Min. operating voltage: 5 V AC

Max. operating voltage: 30 V AC

Operating voltage: 5 - 30 V AC

Outputs: Two-wire

Enclosure material: PA
Steel

Model: Inductive

Installation type: T groove

Connector: Cable

Cable length: 2.50 m

Features: oil-resistant

Min. temperature: -40 °C

Max. temperature: +70 °C

: IP65
IP68

Content: 1 pc(s)

Type: Protection class IP65/IP68

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1943937 FESTO Proximity sensor Inductive SME-8M-ZS-24V-K-2,5-OE 543872 T groove Two-wire

User & Safety Instructions

User & Safety Instructions 1943937 FESTO Proximity sensor Inductive SME-8M-ZS-24V-K-2,5-OE 543872 T groove Two-wire

Description

Proximity switch SME-8M-ZS-24 V-K-2.5-OE electric, with reed contact, two-wire design, for drives with T-slot, assembly from above, with cable. Approval = (* RCM mark, * C UL US LISTED (oil)), CE mark (see declaration of conformity) = after EU EMC Directive, special properties = oil-resistant, material note = (* copper and PTFE-free, * RoHS compliant), measuring principle = Magnetic Reed

This text is machine translated.
