Name: FESTO Vacuum cleaner ESS-200-SS 189332 M20 Nominal width (details) 10 mm Sealant VMQ (silicone)
Brand: FESTO
SKU: 2203910
Availability: BackOrder

A round metal plate with a central threaded hole and four surrounding holes. It is likely used as a mounting adapter.

Image similar

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 379.00 / piece)

€ 379.00

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Technical specifications

Connection position: Top
Mounting type: Via vacuum connection
Operating pressure: 0 ... 0.95 bar
Operating medium: Atmospheric air in accordance with ISO 8573-1:2010 [7:-:-]
All mounting positions permitted
Color: Transparent
Holding force at rated operating pressure: 1,610 N.
Corrosion resistance class KBK: 1 - low corrosion stress
Food suitability: See extended material information
Min Workpiece radius R: 680 mm
Nominal operating pressure: -0.7 bar
Nominal diameter 10 mm
Product weight: 1,198 g
Transverse force at nominal operating pressure 425 N.
Suction unit diameter 200 mm
Suction cup shape: Round flat
Suction unit volume: 245,454 cm3
Shore hardness 50 +/- 5
Ambient temperature: -30 ... 180 °C
Vacuum connection: M20x2
Screw-in bolt material: NBR
Steel, nickel-plated
Galvanized and chrome-plated steel
Material suction unit: VMQ (silicone)
Material information: Free of copper and PTFE
Lab containing substances
Complies with RoHS
Allocation of suction cup holder: Size 6

Operating medium: Atmospheric air

Product type: Vacuum cleaner

Connection: M20

Max. operating pressure: 0.95 bar

Operating temperature: -30 °C (min)

Min. operating temperature: -30 °C

Type: Corrosion resistance class KBK: 1 - low corrosion stress

Manufacturer part #: 189332

Operating pressure (min.): 0 bar

Sealant: VMQ (silicone)

Weight: 1198 g

Medium: Natural air

Nominal width: 10 mm

Max. ambient temperature: +180 °C

Min. ambient temperature: -30 °C

UKCA: yes
