Name: FESTO Vacuum cleaner ESS-4-SU 189270 3 mm Nominal width (details) 1.2 mm Sealant PUR
Brand: FESTO
SKU: 2203848
Availability: BackOrder

A blue component with a cylindrical shape and a narrow upper hole, likely for technical applications.

Image similar

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 12.99 / piece)

€ 12.99

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Technical specifications

Discharge impulse capability:< = 4 bar
Connection position: Top
Mounting type: Via vacuum connection
Operating pressure: 0 ... 0.95 bar
Operating medium: Atmospheric air in accordance with ISO 8573-1:2010 [7:-:-]
All mounting positions permitted
Colour : blue
Holding force at nominal operating pressure 0.46 N.
Corrosion resistance class KBK: 1 - low corrosion stress
Food suitability: See extended material information
Min Workpiece radius R: 10 mm
Nominal operating pressure: -0.7 bar
Nominal diameter 1.2 mm
Product weight: 0.1 g
Transverse force at nominal operating pressure: 0.5 N.
Suction unit diameter 4 mm
Suction cup shape: Round flat
Suction unit volume: 0.008 cm3
Shore hardness 60 +/- 5
Ambient temperature: -20 ... 60 °C
Vacuum connection: External diameter 3 mm
Screw-in pin material: Nickel-plated brass
Material suction unit: Pure
Material information: Free of copper and PTFE
Lab containing substances
Complies with RoHS
Allocation of suction cup holder: Size 1

Operating medium: Atmospheric air

Product type: Vacuum cleaner

Connection: 3 mm

Max. operating pressure: 0.95 bar

Operating temperature: -20 °C (min)

Min. operating temperature: -20 °C

Type: Corrosion resistance class KBK: 1 - low corrosion stress

Manufacturer part #: 189270

Operating pressure (min.): 0 bar

Sealant: PUR

Weight: 0.1 g

Medium: Natural air

Nominal width: 1.2 mm

Max. ambient temperature: +60 °C

Min. ambient temperature: -20 °C

UKCA: not relevant

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2203848 FESTO Vacuum cleaner ESS-4-SU 189270 3 mm Nominal width (details) 1.2 mm Sealant PUR

Hints

The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
