FESTO Vacuum nozzle cartridge VN-10-H 547697 Nominal width (details) 0.95 mm Sealant NBR
EAN:
Part number:
Item no:
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 36.99 / piece)
€ 184.95
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
Technical specifications
- Ventilation time at rated operating pressure: 1.02 s.
- Operating pressure: 1 ... 8 bar
- Operating pressure for max. vacuum: 3.5 bar
- Operating medium: Compressed air according to ISO 8573-1:2010 [7:4:4]
- All mounting positions permitted
- Ejector characteristic: Standard
- High vacuum
- Note on operating and control medium: Oiled operation not possible
- Corrosion resistance class KBK: 2 - moderate corrosion stress
- Max. Suction volume flow against atmosphere: 21.8 l/min.
- Max. Vacuum: 0.93
- Medium temperature: 0 ... 60 °C
- Nominal operating pressure 6 bar
- Nominal diameter of lava nozzle: 0.95 mm
- Product weight: 1,65 g
- Ambient temperature: 0 ... 60 °C
- Material seals: NBR
- Material: POM
- Material jet nozzle: Aluminum wrought alloy
- Operating medium
Compressed Air
- Product type
Vacuum nozzle cartridge
- Max. operating pressure
8 bar
- Type
Corrosion resistance class KBK: 2 - moderate corrosion stress
- Manufacturer part #
547697
- Operating pressure (min.)
1 bar
- Sealant
NBR
- Weight
1.65 g
- Medium
Compressed air
- Nominal width
0.95 mm
- Max. ambient temperature
+60 °C
- Min. ambient temperature
0 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2204423 FESTO Vacuum nozzle cartridge VN-10-H 547697 Nominal width (details) 0.95 mm Sealant NBR
Description
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
