Name: FESTO Vacuum nozzle VN-20-L-T6-PQ4-VA5-RO2 526135 QS-10, Muffler Nominal width (details) 2 mm Enclosure material POM Sea
Brand: FESTO
SKU: 2204220
Availability: BackOrder

Technical drawing of a hydraulic valve with two connected cylinders. Used for controlling liquid flows in systems.

Image similar

Sales and shipping:

Conrad ElectronicTerms & Conditions

Total (€ 194.99 / piece)

€ 194.99

incl. VAT

Only available for business customers

14-day return policy included

Report legal concerns

Highlights & Details

Technical specifications

Type of silencer: Open
Mounting type: With through hole
With accessories
Ventilation time at nominal operating pressure: 0.15 s.
Operating pressure: 1 ... 8 bar
Operating pressure for max. suction volume flow: 3 bar
Operating medium: Compressed air according to ISO 8573-1:2010 [7:4:4]
All mounting positions permitted
Ejector characteristic: High suction volume current
Standard
Note on operating and control medium: Oiled operation not possible
Integrated function: Muffler open
Constructive structure: T-shape
Corrosion resistance class KBK: 1 - low corrosion stress
Max. Tightening torque: 0.8 Nm
Max. Suction flow against atmosphere: 188 l/min.
Medium temperature: 0 ... 60 °C
Nominal operating pressure 6 bar
Nominal diameter Laval nozzle: 2 mm
Pneumatic connection 1: QS-10
Pneumatic connection 3: Muffler open
Product weight: 200 g
Pitch: 24 mm
Sound pressure level at rated operating pressure 60 dB(A)
Ambient temperature: 0 ... 60 °C
Vacuum connection: g1/4
Material connection thread: Aluminum wrought alloy
Material seals: NBR
Material: POM
Material casing: POM-reinforced
Material silencer: Die-cast aluminum
POM
PU foam
Material jet nozzle: Aluminum wrought alloy
Screw connection material: Brass
Nickel-plated
Material information: Free of copper and PTFE
Lab containing substances
Complies with RoHS

Operating medium: Compressed Air

Type: 526135

Product type: Vacuum nozzle

Enclosure material: POM

Connection: QS-10
Muffler

Max. operating pressure: 8 bar

Operating temperature: 0 °C (min)

Min. operating temperature: 0 °C

Type: Corrosion resistance class KBK: 1 - low corrosion stress

Manufacturer part #: 526135

Operating pressure (min.): 1 bar

Sealant: NBR

Weight: 189 g

Media temperature (range): 0 up to 60 °C

Max. media temperature: 60 °C

Media temperature (min.): 0 °C

Medium: Compressed air

Nominal width: 2 mm

Features: P port connector (G1/4)

Max. ambient temperature: +60 °C

Min. ambient temperature: 0 °C

UKCA: not relevant
