Finder 22.44.0.024.4410 Remote switch 4 breakers 440 V AC Compatible with (relay brand): Finder Piece 1 pc(s)
Product type
Remote switch
No. of pins
4-pin
Nominal voltage
440 V AC
Packaging type
Piece
Type
22.44.0.024.4410
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 81.99 / piece)
€ 81.99
incl. VAT
14-day return policy included
Technical specifications
- Installation depth: 63.1 mm
- Number of division units: 3
- Usage category: 3
- Max. Bulb load 4000 W
- Max. Fluorescent lamp load 1500 VA
- Max. Fluorescent lamp load (Duo-circuit): 1500 VA
- Max. Fluorescent lamp load (compensated in parallel): 1500 VA
- Packaging type
Piece
- Product type
Remote switch
- Type
22.44.0.024.4410
- No. of pins
4-pin
- Contact type
4 breakers
- Contact material
AgSnO2
- Auxiliary contact type
4 breakers
- Nominal voltage
440 V AC
- Switching voltage (max.)
24 V DC/AC
- Permanent current (max.)
40 A
- Compatible with
Finder
- Compatible with series
Finder 22.44 series
- Mounting type
DIN rail
IP20
- Width
53.5 mm
- Depth
63.1 mm
- Dim
(W x D) 53.5 mm x 63.1 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
53.5
95.8 mm
63.1 mm
TRUE
11 kW
0
4
0
0
22 A
40 A
24-24 V
24-24 V
24-24 V
Screw connection
20.4-26.4 V
20.4-26.4 V
AC/DC
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2474629 Finder 22.44.0.024.4410 Remote switch 4 breakers 440 V AC Compatible with (relay brand): Finder Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2474629 Finder 22.44.0.024.4410 Remote switch 4 breakers 440 V AC Compatible with (relay brand): Finder Piece 1 pc(s)
Description
Installation contactor for 35 mm rail, 4 NC contacts for 40 A / 440 V AC, contact material AgSnO2, max. switching power at 230 V AC: AC1-AC-7a: 16 kVA, rated current AC3-AC7b 22 A, glow and halogen lamps 4000 W, fluorescent lamps with EVG 1500 W, fluorescent lamps-uncompensated 1500 W, energy saving lamps 1000 W, LED (230 V AC) 1000 W, LV halogen lamps or LED with EVG 1000 W, NV halogen lamps or LED with KVG 1500 W. Coil 24 V AC/DC, Width 53.5 mm, mechanical switching position display, Relay protection type: IP 20
