Finder 45.91.7.009.0310 PCB relay 9 V DC 16 A 1 maker 1 pc(s)
Product type
PCB relay
Coil nominal voltage
9 V DC
Contact type
1 maker
Switching voltage (max.)
250 V AC
Switching current (max.)
16 A
EAN:
Part number:
Item no:
Number
Total (€ 6.99 / piece)
€ 6.99
incl. VAT
14-day return policy included
Highlights & Details
Our service for you
Technical specifications
- With removable terminals: No.
- Drive, polarity: Non-polar
- Switching characteristics of drive: Mono-stable
- With positively driven contacts: No.
- Type of switch contact: Single contact
- Complete unit with socket: No.
- Product type
PCB relay
- Type
45.91.7.009.0310
- Coil nominal voltage
9 V DC
- Coil voltage rating
0.36 W
- Contact type
1 maker
- Contact material
AgNi
- Switching voltage (max.)
250 V AC
- Switching current (max.)
16 A
- Connection
Print
IP40
- Max. temperature
125 °C
- Width
12.5 mm
- Height
28.5 mm
- Depth
40.7 mm
- Dim
(W x H x D) 12.5 x 28.5 x 40.7 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3323071 Finder 45.91.7.009.0310 PCB relay 9 V DC 16 A 1 maker 1 pc(s)
Description
Power/PCB relay with Faston 250, 1 closer for 16 A / 250 V AC, 3 mm contact opening, contact material AgNi, coil data 9 V DC, 0.36 W, 225 Ohm, relay protection type RT II, high-temperature version 125°C
