Name: Finder SSR 77F182308650 80 A Switching voltage (max.): 660 V AC Zero crossing 1 pc(s)
Brand: Finder
SKU: 3343706
Availability: BackOrder

A two-pole relay module for industrial applications, showing connections for load and input. Specifications and CE marking are visible.

Image similar

Packaging type

Piece

Product type

SSR

Switching voltage (max.)

660 V AC

Current load (max.)

80 A

Output voltage (max.)

660 V AC

Datasheet (PDF)

Available soon

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 61.99 / piece)

€ 61.99

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Input voltage 230 Vac
Inrush current: Up to 800 A for 10 ms
Minimum switching current 100 mA at 250 V/AC
Thermal output at In:96 W
Periodic Peak Reverse Voltage: 1600 Vpk
Residual current in "OFF" state at rated voltage: 0.1 mA
Dielectric strength input to output 4 kV
Design: With LED

Packaging type: Piece

Product type: SSR

Type: 77.F1.8.230.8650

Switching type: Zero crossing

Surge current (max.): 800 A

Switching voltage (min.): 24 V AC

Switching voltage (max.): 660 V AC

Current load (max.): 80 A

Output voltage (min.): 24 V AC

Output voltage (max.): 660 V AC

Max. output current: 80 A

Contact type: 1 maker

Min. temperature: -30 °C

Max. temperature: +80 °C

: IP20

Width: 45 mm

Height: 29.40 mm

Depth: 59 mm

Length: 59 mm

RoHS-compliant: Yes

Permanent current (max.): 80 A

Content: 1 pc(s)

Nominal control voltage: 230 V AC

Documents & Downloads

Datasheet

Datasheet 3343706 Finder SSR 77F182308650 80 A Switching voltage (max.): 660 V AC Zero crossing 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3343706 Finder SSR 77F182308650 80 A Switching voltage (max.): 660 V AC Zero crossing 1 pc(s)

Features

SSR relay;
Hockey puck housing with fold-out terminal cover
Long life and switching speed
Noiseless switching
Arc-and bounce-free switching
Low control power
For mounting on a control cabinet or heatsink
This text is machine translated.

Description

Features

SSR relay;
Hockey puck housing with fold-out terminal cover
Long life and switching speed
Noiseless switching
Arc-and bounce-free switching
Low control power
For mounting on a control cabinet or heatsink
This text is machine translated.
