Name: GIRA Pushbuttton 312600 1 pc(s)
Brand: GIRA
SKU: 3823419

Technical specifications

Suitable for protection class (IP): IP20
Material: Other
Material quality: Other
Surface protection: Other
Mounting type: Claw / screw attachment
Connection type: Plug-in terminal
Halogen-free: No.
Compatible with Apple HomeKit: No.
Compatible with Google Assistant: No.
Compatible with Amazon Alexa: No.
IFTTT support available: No.
Antibacterial treatment: No.
Operating mode rocker/button
Lighting: No.
Assembly: Base element
Switching type: Toggle switch
Key switch: Yes
Number of operating rockers: 1
With mounting plate: No.
Text field/label area: No.
Feedback contact: No.
Heating switch: No.
Washing machine switch: No.
Number of modules (for modular design): 1
Rated current 10 A

Type: Push button switch Auswe use 312600

Product type: Pushbuttton

Nominal voltage: 250 V

Content: 1 pc(s)

Mounting type: Flush mount

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3823419 GIRA Pushbuttton 312600 1 pc(s)

Description

Use of push-button switches 10 AX 250 V~ Universal-off changeover switch Features: - Unlike rocker switches, the rocker switches always return to their starting position after each actuation. - The resulting uniform tipping position allows an orderly and high-quality picture of the electrical installation. - The aesthetics are significantly increased, especially in the case of multiple combinations, e.g. with several switches in one frame. - Floating rocker provides automatic and precise positioning of the rocker in the cover frame. - Quick mounting (3.5 turns per mounting claw). - Easier claw attachment with rugged screw head drive PZ1 / slit / PH - Voltage testing possible from the front. - Uniform stripping length (11 mm) for switches and sockets ensures faster and more efficient mounting. - The use of rigid and flexible conductor material is possible. - Easily accessible release levers. - Unbreakable thermoplastic base. - Standard LED lighting elements can be used from the front. - By turning the lighting element at 180°, it is possible to change between the control lighting and continuous lighting depending on the switch. Notes: - Can also be illuminated.

This text is machine translated.

Description

Use of push-button switches 10 AX 250 V~ Universal-off changeover switch Features: - Unlike rocker switches, the rocker switches always return to their starting position after each actuation. - The resulting uniform tipping position allows an orderly and high-quality picture of the electrical installation. - The aesthetics are significantly increased, especially in the case of multiple combinations, e.g. with several switches in one frame. - Floating rocker provides automatic and precise positioning of the rocker in the cover frame. - Quick mounting (3.5 turns per mounting claw). - Easier claw attachment with rugged screw head drive PZ1 / slit / PH - Voltage testing possible from the front. - Uniform stripping length (11 mm) for switches and sockets ensures faster and more efficient mounting. - The use of rigid and flexible conductor material is possible. - Easily accessible release levers. - Unbreakable thermoplastic base. - Standard LED lighting elements can be used from the front. - By turning the lighting element at 180°, it is possible to change between the control lighting and continuous lighting depending on the switch. Notes: - Can also be illuminated.

This text is machine translated.
