Image similar
Image similar
HARTING 09662286700 D-SUB pin strip 180 ° Number of pins: 15 Cut & Clip 1 pc(s)
EAN:
Part number:
Item no:
Product type
D-SUB pin strip
Connector type
Plug, vertical mount
Number of pins
15
Connection
Cut & Clip
No. of rows
2
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
100
-
€ 12.60
300
6% = € 0.70
€ 11.90
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 100
Multiple: 100
Total (€ 12.60 / piece)
€ 1,260.00
plus VAT.
Highlights & Details
HARTING 09662286700 D-SUB pin strip 180 ° Number of pins: 15 Cut & Clip 1 pc(s)
- D-SUB pin strip
- No. of rows: 2
- Number of pins: 15
Our service for you
Technical specifications
- Insulation displacement
- For wire cross-sections: AWG 28/7/AWG 26/7 wires, AWG 30/1/AWG 28/1 solid wires.
- Product type
D-SUB pin strip
- Connector type
Plug, vertical mount
- Number of pins
15
- Connection
Cut & Clip
- Connection angle
180°
- No. of rows
2
- Content
1 pc(s)
- Manufacturer part #
09662286700
- Certification marks
DIN 41652, CECC 75 301-802, IEC 60807
- RoHS-compliant
Yes
- Features
+ protective steel collar with dimples
- Temperature range
-55ºC - +125 °C
- Type
09662286700
- Type
pin strip
- Thread size
3.1 mm
- Nominal current (details)
Max. 2 A
- Pitch
1.27 mm
- Connection
Stranded conductor - AWG 28 / 7, AWG 26 / 7
Solid conductor - AWG 30 / 1, AWG 28 / 1
- Casing
Thermoplastischer Formstoff, glasfaserverstärkt (PBTP)
Documents & Downloads
Datasheet
Datasheet 742403 HARTING 09662286700 D-SUB pin strip 180 ° Number of pins: 15 Cut & Clip 1 pc(s)
User & Safety Instructions
User & Safety Instructions 742403 HARTING 09662286700 D-SUB pin strip 180 ° Number of pins: 15 Cut & Clip 1 pc(s)
Description
Machined contacts and Shield ripple in protective metal collar, requirement level 2
Scope of delivery
- Batteries not included
