Automation & PneumaticsPneumatics & All FluidValves & Cut-offsBall Valves

IMI NORGREN 602113168EX Ball valve Internal thread: G3/4" 0 up to 12 bar 1 pc(s)

Brass ball valve with black handle, horizontally positioned, showing left-hand external thread. For flow control in piping applications.
Image similar
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Thu 5 Nov
58 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 43.99 / piece)
€ 43.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Product type

Ball valve

Internal thread

G3/4"

Internal thread (details)

G3/4" inch

Manufacturer part #

602113168EX

Operating temperature

0 °C (min)

Min. operating temperature

0 °C

Max. operating pressure

12 bar

Operating pressure (min.)

0 bar

Pressure range

0 up to 12 bar

Operating medium

Compressed air

Water

Mineral oil

(Ø)

20 mm

Height

98.5 mm

Length

158.5 mm

Width

45 mm

Max. ambient temperature

+60 °C

Min. ambient temperature

0 °C

Documents & Downloads

Datasheet

Datasheet 3297010 IMI NORGREN 602113168EX Ball valve Internal thread: G3/4" 0 up to 12 bar 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3297010 IMI NORGREN 602113168EX Ball valve Internal thread: G3/4" 0 up to 12 bar 1 pc(s)

Description

Valve 602113168EX 60 Series Ball Valves
