Several silver pipe fittings and adapters in various shapes and sizes on a black background.

Image similar

Several silver pipe fittings and adapters in various shapes and sizes on a black background.

Image similar

IMI NORGREN

Datasheet (PDF)

English

Fast track dispatch on Wed, 23 Sep

7 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 25.20 / piece)

€ 25.20

plus VAT.

Only 7 Piece(s) available

14-day return policy included

Report legal concerns

Technical specifications

Product type: Elbow connector (pivoted)

Operating temperature: -18 °C (min)

Min. operating temperature: -18 °C

Manufacturer part #: 16A514848

Dim: (L x W x H) 62 x 30 x 47 mm

Max. operating pressure: 18 bar

Operating pressure (min.): -09 bar

Pressure range: -09 up to 18 bar

Content: 1 pc(s)

Width: 30 mm

Height: 47 mm

Length: 62 mm

Max. ambient temperature: 70 °C

Min. ambient temperature: -18 °C

Documents & Downloads

Datasheet

English

Datasheet 3300995 IMI NORGREN Elbow connector (pivoted) -09 up to 18 bar

User & Safety Instructions

User & Safety Instructions 3300995 IMI NORGREN Elbow connector (pivoted) -09 up to 18 bar
