Several silver pipe connectors and fittings in different shapes and sizes arranged against a black background.

Image similar

Several silver pipe connectors and fittings in different shapes and sizes arranged against a black background.

Image similar

IMI NORGREN

Datasheet (PDF)

English

Dispatches on Fri, 25 Sep

1489 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Minimum order quantity: 10

Multiple: 10

Total (€ 20.16 / piece)

€ 201.60

plus VAT.

14-day return policy included

Report legal concerns

Technical specifications

Product type: Elbow connector (pivoted)

Operating temperature: -18 °C (min)

Min. operating temperature: -18 °C

Manufacturer part #: 16A513838

Dim: (L x W x H) 44 x 25 x 45 mm

Max. operating pressure: 18 bar

Operating pressure (min.): -09 bar

Pressure range: -09 up to 18 bar

Content: 1 pc(s)

Width: 25 mm

Height: 45 mm

Length: 44 mm

Max. ambient temperature: 70 °C

Min. ambient temperature: -18 °C

Documents & Downloads

Datasheet

English

Datasheet 3300994 IMI NORGREN Elbow connector (pivoted) -09 up to 18 bar

User & Safety Instructions

User & Safety Instructions 3300994 IMI NORGREN Elbow connector (pivoted) -09 up to 18 bar
