Isometric illustration of a two-digit seven-segment LED display component with pins underneath.<br>

Isometric illustration of a two-digit seven-segment LED display component with pins underneath.<br>

Kingbright

Product type

Seven-segment display

Forward voltage U(F)

1.95 V

2.5 V

Shared connection

Anode

Width

12.4 mm

Height

17.5 mm

Datasheet (PDF)

Part number:

Item no:

Fast track dispatch on Thu 5 Nov

1987 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 1.99 / piece)

€ 1.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Single digit 7-segment LED display 13.2mm red

High-efficiency super bright red (AlGaInP technology) with high light intensity (up to 85 mcd @ 10 mA)
Circuit with common anode (common anode) and gray casing surface with white segments for optimum contrast
Simple mounting on circuit boards (through-hole/THT) with low power consumption and high reliability

Technical specifications

Chip-Material: AlGaInP
Grey front with white segments
Pin spacing (Spacing) 2.54 mm
Row spacing 15.24 mm (0.6 inches)
Decimal point: Right anode (RHDP)

Product type: Seven-segment display

Type: SA52-11SURKWA

Forward voltage U(F): 1.95 V
2.5 V

Forward current I(F): 20 mA
30 mA

Shared connection: Anode

Factory colour: Red

Width: 12.4 mm

Wavelength: 630 nm

Height: 17.5 mm

Light intensity I(V): 31 mcd
75 mcd

Digit height: 13.2 mm

No. of digits: 1

Dim: (L x W x H) 17.5 x 12.4 x 17.5 mm

Length: 17.5 mm

Depth: 7 mm

RoHS-compliant: Yes

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3825275 Kingbright Seven-segment display Red 13.2 mm 1.95 V, 2.5 V No. of digits: 1 SA52-11SURKWA

User & Safety Instructions

User & Safety Instructions 3825275 Kingbright Seven-segment display Red 13.2 mm 1.95 V, 2.5 V No. of digits: 1 SA52-11SURKWA

Description

Single 7-segment LED display 13.2mm red for digit display

This text is machine translated.

Scope of delivery

7-segment LED display

Description

Single 7-segment LED display 13.2mm red for digit display

This text is machine translated.

Scope of delivery

7-segment LED display
