Name: Kingbright Seven-segment display Red 2 V PSC08-11EWA
Brand: Kingbright
SKU: 2888919
Availability: InStock

A 7-segment LED display with unlit segments. Several pins for electrical connection are located to its right.

Product type

Seven-segment display

Forward voltage U(F)

2 V

Width

8.5 mm

Height

27.7 mm

Type

PSC08-11EWA

EAN:

Part number:

Item no:

Fast track dispatch on Thu 29 Oct

172 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 3.49 / piece)

€ 3.49

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

Kingbright PSC08-11EWA 20.3mm High Efficiency Red Starburst Display Cathode

Our service for you

Technical specifications

Product type: Seven-segment display

Type: PSC08-11EWA

Forward voltage U(F): 2 V

Forward current I(F): 30 mA

Factory colour: Red

Width: 8.5 mm

Wavelength: 627 nm

Height: 27.7 mm

Light intensity I(V): 4.7 mcd

Dim: (L x W x H) 20 x 8.5 x 27.7 mm

Length: 20 mm

RoHS-compliant: Yes

Type: Radial lead

Max. temperature: +85 °C

Min. temperature: -40 °C

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2888919 Kingbright Seven-segment display Red 2 V PSC08-11EWA

Features

Right hand decimal
Low current operation
High contrast and light output
Easy mounting on PCBs or sockets
Mechanically rugged
Grey face with white segments
Common cathode
This text is machine translated.

Description

Features

Right hand decimal
Low current operation
High contrast and light output
Easy mounting on PCBs or sockets
Mechanically rugged
Grey face with white segments
Common cathode
This text is machine translated.
