Kingbright Seven-segment display Red 2 V SC32-11HWA

A seven-segment LED display showing the digit 0. Electronic component with four pin connectors on the right-hand side.
Product type
Seven-segment display
Forward voltage U(F)
2 V
Width
6.5 mm
Height
13 mm
Type
SC32-11HWA
EAN:
Part number:
Item no:
Available soon
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Minimum order quantity: 5
Total (€ 1.99 / piece)
€ 1.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Kingbright SC32-11HWA 8mm Red LED Display Cathode

Our service for you

Technical specifications

  • Common cathode
Product type

Seven-segment display

Type

SC32-11HWA

Forward voltage U(F)

2 V

Forward current I(F)

25 mA

Factory colour

Red

Width

6.5 mm

Height

13 mm

Light intensity I(V)

0.9 mcd

Dim

(L x W x H) 7.5 x 6.5 x 13 mm

Length

7.5 mm

RoHS-compliant

Yes

Casing

8 mm

Type

Radial lead

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2888908 Kingbright Seven-segment display Red 2 V SC32-11HWA

Description

Features

  • Ideally suited to applications where board space is at a premium
  • Right hand decimal point
  • Low current operation
  • Excellent character appearance
  • Easy mounting on PCB
  • IC compatible
  • Common cathode
  • Dimensions 13 x 7.5 x 6.5mm
  • Kingbright S32 series
  • This text is machine translated.
