KS Tools 640.0310 Puller Clamping range (details) 350 mm No. of hooks 3
EAN:
Part number:
Item no:
Number
Total (€ 309.00 / piece)
€ 309.00
incl. VAT
Only 2 Piece(s) available
Technical specifications
- Pull hook width G: 30 mm
- Pull hook total depth F: 48 mm
- Pull hook height D 5 mm
- Pull hook tip depth E: 25 mm
- Number of pull hooks: With 3 pull-off hooks
- Torque max. Nm: - Nm
- Functional attribute 1: Adjustable clamping depth
- Weight 9500 g
- Material1: Special tool steel
- max. Compressive strength KN: 100.0
- max. Pressure force t: 10
- Quick adjustment: No. nein
- Clamping depth B in mm 250 mm
- Span A in mm 350 mm
- Spindle size mm UNC2.1/4" x 14
- Variant items : 640.0310
- Clamping range
350 mm
- Tension/pressure capacity
10 t
- Weight
9500 g
- Content
1 pc(s)
- Hooks
3
- Product type
Puller
- Span width (max.)
350 mm
- Span depth (max.)
250 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2695515 KS Tools 640.0310 Puller Clamping range (details) 350 mm No. of hooks 3
Description
Consisting of a crossbar and hookThe clamping depth of hooks can be adjustedEven load distribution and centered tighteningWithout hydraulic pressure spindle/without hydraulic cylinderWithout hydraulic pumpSpecial tool steel
This text is machine translated.
This text is machine translated.
