Lite-On Seven-segment display Red 10 mm 2 V No. of digits: 1 LTS -4301 JR

A 7-segment LED display shows the number zero. It has eight pins and is commonly used in electronic devices to display digits.
Image similar
Product type
Seven-segment display
Forward voltage U(F)
2 V
Shared connection
Cathode
Width
11.4 mm
Height
12.9 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 30 Oct
3068 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Minimum order quantity: 36
Multiple: 36
Total (€ 0.73 / piece)
€ 26.28
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Product type

Seven-segment display

Type

LTS -4301 JR

Forward voltage U(F)

2 V

Forward current I(F)

20 mA

Shared connection

Cathode

Factory colour

Red

Width

11.4 mm

Wavelength

639 nm

Height

12.9 mm

Light intensity I(V)

0.52 mcd

Digit height

10 mm

No. of digits

1

Dim

(W x H x D) 11.4 x 12.9 x 9.7 mm

Depth

9.7 mm

Documents & Downloads

Datasheet

Datasheet 1127503 Lite-On Seven-segment display Red 10 mm 2 V No. of digits: 1 LTS -4301 JR

User & Safety Instructions

User & Safety Instructions 1127503 Lite-On Seven-segment display Red 10 mm 2 V No. of digits: 1 LTS -4301 JR
