A three-legged transistor in a TO-220 package with a metal back and mounting hole for cooling and installation in electronic projects.

A three-legged transistor in a TO-220 package with a metal back and mounting hole for cooling and installation in electronic projects.

Packaging type

Tube

Enclosure

TO 247AD

Product type

Thyristor (SCR)

Type

CS30-12IO1

Manufacturer

Littelfuse

Littelfuse

Fast track dispatch on Fri, 11 Sep

30 Piece(s) (Only while stocks last)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Minimum order quantity: 30

Multiple: 30

Total (€ 3.61 / piece)

€ 108.30

plus VAT.

Report legal concerns

Technical specifications

Package type TO-247AD
Case temperature 120 °C
Max surge current thy amp 400 a
Maximum virtual junction temperature: 150 °C.
Threshold voltage for Power loss calculation Thyristor: 0.87 V
Slope Resistance Thyristor mohm: 14.2 mΩ
Thermal resistance caeseatsink KW:0.25 K/W.
Thermal resistance [junction-case] [Thy] (K/W): 0.5 K/W.
Max Repetitive RevFwd Blocking Voltage: 1200 V
Average forward current: 30 A
DV/dt (V/µs) 1000 V/µs

Packaging type: Tube

Type: CS30-12IO1

Enclosure: TO 247AD

Manufacturer: Littelfuse

Average forward current I(T)(AV): 30 A

Product type: Thyristor (SCR)
