Name: Lumberg 156738 4580 03 OP T2,0 V12VP12 High current contact element CuCr 60 A 1 pc(s)
Brand: Lumberg
SKU: 3805203
Availability: InStock

Metal orthodontic dental appliance with several looped arches mounted on a small base<br>

Product type

High current contact element

Contact material

CuCr

Content

1 pc(s)

Mating cycles

≤ 5

Manufacturer part #

156738

Datasheet (PDF)

Fast track dispatch on Wed 14 Oct

2100 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 0.66 / piece)

€ 0.66

incl. VAT

14-day return policy included

Report legal concerns

Technical specifications

Number of pins: 1
Temperature range --40°C/+120°C
Contact with: Flat blade terminal 5.3–7.2 mm x 1.5–2.0 mm | suitable for reflow soldering on a PCB | suitable for laser welding on a power rail or a connection frame
Plug-in force: Flat-blade knife 1.5 mm | 35 N ± 10 N – plugged from above or below | Flat-pin blade terminal 2.0 mm | 35 N ± 10 N – inserted from above | 50 N ± 10 N – inserted from below
Extraction rate:6 N +10/-3 N
Draw force hint: Measured with polished steel knives
Constant resistance < 0.5 mΩ
Rated current ≤ 60 A
Rated current - Note: Depending on the connection to the circuit board / conductor rail, the installation situation and the heat dissipation

Product type: High current contact element

Contact material: CuCr

Content: 1 pc(s)

Mating cycles: ≤ 5

Manufacturer part #: 156738

Contact surface: Tin plated

Nominal current: 60 A

Type: 4580 03 OP T2,0 V12VP12

Documents & Downloads

Datasheet

Datasheet 3805203 Lumberg 156738 4580 03 OP T2,0 V12VP12 High current contact element CuCr 60 A 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3805203 Lumberg 156738 4580 03 OP T2,0 V12VP12 High current contact element CuCr 60 A 1 pc(s)

Description

High current contact socket in Surface-Mount technology (SMT), can be plugged from above or below, for blade contacts 1.5–2.0 mm, for circuit boards or conductor rails

This text is machine translated.
