Lumel EA17 500V EA17 500V Panel-mounted measuring device 72 x 72 mm 500 V AC Moving iron

Analogue ammeter shows a current of 0 amperes. Scale from 0 to 20. Manufacturer name 'LUMEL' is visible at the bottom.
Image similar
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
5 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 43.99 / piece)
€ 43.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
Only 5 Piece(s) available
14-day return policy included
Report legal concerns

Highlights & Details

Panel-mounted measuring device 72 x 72 mm

  • Assembly dimensions 68 x 68 mm

Technical specifications

  • Connection angle 90°
Product type

Analogue rack-mount meter

Reading type

AC voltage

Reading range (max.)

500 V

Dim

(W x H) 72 mm x 72 mm

Recess width

68 mm

Instrument type

Moving iron

Recess height

68 mm

Temperature range

-10 to +55 °C

Type

EA17 500V

Content

1 pc(s)

Width

72 mm

Height

72 mm

Frame width

72 mm

Manufacturer's standards (no certificate)

IP50

Connections

Direct connection

Assembly dimensions

68 x 68 mm

Accuracy class

1.5

Type

EA 17

Reading range

500 V AC

Documents & Downloads

Datasheet

Datasheet 1383449 Lumel EA17 500V EA17 500V Panel-mounted measuring device 72 x 72 mm 500 V AC Moving iron

User & Safety Instructions

User & Safety Instructions 1383449 Lumel EA17 500V EA17 500V Panel-mounted measuring device 72 x 72 mm 500 V AC Moving iron

Conformity certificate

Conformity certificate 1383449 Lumel EA17 500V EA17 500V Panel-mounted measuring device 72 x 72 mm 500 V AC Moving iron

Description

The Rotary Iron Meter is used for the measurement of alternating voltages in the frequency range from 40…72 Hz. In this frequency range show practically independent of the curve shape the effective value. Only in the case of extreme curve shapes (e.g. in case of phase control controls), the class accuracy is no longer observed. The front frame, the front windscreen and the scale can be easily replaced.

This text is machine translated.

Features

  • Incl. Terminal cover and screw clamp mounting

Scope of delivery

  • 2 fastening elements
  • Terminal cover
  • User manual.
