Lutronic 1057 Sensor/actuator cable M8 1.50 m No. of pins (RJ): 4 1 pc(s)

Two circles show numbers 1 to 4. The left circle has three empty and one filled segment, the right circle the opposite.
Two circles with four quadrants each. Left: Quadrants 1, 2 unmarked, 3, 4 marked. Right: Quadrants 1, 2, 3, 4 marked.
Technical drawing of a connector with length specifications: Total length 132 mm, Internal elements from 32 mm to 95 mm.
1/3
Stroke drawing/circuit diagram
Product type
Sensor/actuator cable
Connector standard
Sensor connector
Connection side A
M8 plug, straight
Connection side B
M8 socket, straight
No. of pins
4
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
14 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 16.99 / piece)
€ 16.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

Type

0810 0800 04 301 1,5m

Product type

Sensor/actuator cable

Connector standard

Sensor connector

Connection side A

M8 plug, straight

Connection side B

M8 socket, straight

No. of pins

4

Cable length

1.50 m

Jacket material

PUR

Nominal voltage

60 V

Nominal current

4.0 A

Nominal current - rounded value

4 A

Outside Ø

10 mm

Factory colour

Black

Thread type connection side

M8

Thread type (wiring and installation)

M8

Cable colour

Black

Coding

A

Contact material

Brass, nickel and gold plated

Contact surface

TPU

IP67

Min. temperature

-25 °C

Max. temperature

80 °C

Seal type

Screw-on

Manufacturer part #

1057

Content

1 pc(s)

Documents & Downloads

Datasheet

Datasheet 1910572 Lutronic 1057 Sensor/actuator cable M8 1.50 m No. of pins (RJ): 4 1 pc(s)
