Compact, rectangular voltage converter from MEAN WELL with four metal pins, model number RDC10-Q24-D5, featuring CE and EAC certificates.

Compact, rectangular voltage converter from MEAN WELL with four metal pins, model number RDC10-Q24-D5, featuring CE and EAC certificates.

MEAN WELL

Datasheet (PDF)

English

1 Piece(s)

Sales and shipping:

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 21.84 / piece)

€

Only 1 Piece(s) available

Report legal concerns

Highlights & Details

MEANWELL DC/DC converter modules series RSDW10, RDDW 10 DIP 24/DIL 24 case single and dual output input voltage ratio: 4:1 Power: 10 W Railway

In the DIP 24/DIL 24-housing
For direct PCB mounting
Input voltage range 4:1
No minimum load required
Input/output insulation 3000 V DC
Protection: short circuit (continuously), overload, over voltage and input voltage
Efficiency up to 88%
This text is machine translated.

Technical specifications

Product type: DC/DC converter

Type: RDDW10H-12

Min. input voltage: 43 V DC

Input voltage (max.): 160 V DC

No. of outputs: 2 x

Max. output current: 416 mA

Output current (max.) - rounded: 416 mA

Efficiency (max.): 87 %

: 10 W

Insulation voltage: 3000 V DC

Connection: Pins

PSU features: DC-to-DC converter

Operating temperature (min.): -40 °C

Operating temperature (max.): +85 °C

Dim: (L x W x H) 31.8 x 20.3 x 12.7 mm

Height: 12.7 mm

Length: 31.8 mm

Width: 20.3 mm

RoHS-compliant: Yes

Output voltage (max.): 12 V DC
-12 V DC

Weight: 16 g

Content: 1 pc(s)

Documents & Downloads

Datasheet

English

Datasheet 2143420 MEAN WELL RDDW10H-12 DC/DC converter 416 mA 10 W No. of outputs: 2 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2143420 MEAN WELL RDDW10H-12 DC/DC converter 416 mA 10 W No. of outputs: 2 x Content 1 pc(s)

Warranty Terms

European union

Warranty Terms 2143420 MEAN WELL RDDW10H-12 DC/DC converter 416 mA 10 W No. of outputs: 2 x Content 1 pc(s)

Description

Features

In the DIP 24/DIL 24-housing
For direct PCB mounting
Input voltage range 4:1
No minimum load required
Input/output insulation 3000 V DC
Protection: short circuit (continuously), overload, over voltage and input voltage
