MEAN WELL SPBW03F-12 DC/DC converter (module) 250 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 17.99 / piece)
€ 17.99
incl. VAT
14-day return policy included
Highlights & Details
MEANWELL DC/DC converter modules series SPBW03 SIP/SIL 8 Case Single Output Input voltage ratio: 4:1 Power 3 W regulated
- SIP/SIL8-casing
- For direct PCB mounting
- Input voltage ratio: 4:1
- No minimum load required
- Input/output insulation 1500 V
- Regulated output voltage
- According to EN 55032 Class A transmitted without additional components
- Efficiency up to 85%
- Remote control
Technical specifications
- Product type
DC/DC converter (module)
- Type
SPBW03F-12
- Min. input voltage
9 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Max. output current
250 mA
- Output current (max.) - rounded
250 mA
- Efficiency (max.)
84 %
3 W
- Insulation voltage
1500 V DC
- Connection
Pins
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+85 °C
- Dim
(L x W x H) 21.8 x 9.2 x 11.1 mm
- Height
11.1 mm
- Length
21.8 mm
- Width
9.2 mm
- RoHS-compliant
Yes
- Output voltage (max.)
12 V DC
- Weight
4.8 g
- Content
1 pc(s)
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2143639 MEAN WELL SPBW03F-12 DC/DC converter (module) 250 mA 3 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2143639 MEAN WELL SPBW03F-12 DC/DC converter (module) 250 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 2143639 MEAN WELL SPBW03F-12 DC/DC converter (module) 250 mA 3 W No. of outputs: 1 x Content 1 pc(s)
Description
With the introduction of regulated DC/DC converters SPBW03 (Single Output) offers mean well with standard SIP Pin assignment. In addition to a wide input range 4:1 and a wide operating temperature range from -40 up to +90 °C, all with 1500 V DC I/O insulation. Suitable applications include IoT, electronics, telecommunications, networking, industrial control and distributed power architecture.
This text is machine translated.
This text is machine translated.
Features
- SIP/SIL8-casing
- For direct PCB mounting
- Input voltage ratio: 4:1
- No minimum load required
- Input/output insulation 1500 V
- Regulated output voltage
- Efficiency up to 85%
- Remote control
