Molex Built-in pin strip (standard) 254 Total number of pins 8 Contact spacing: 2.54 mm 22272081 1 pc(s) Bag

A white, rectangular plug connector with ten metal pins on a white surface.
Product type
Built-in pin strip (standard)
No. of rows
1
Series
254
CS
2.54 mm
Total number of pins
8
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
1163 Piece(s) (Only while stocks last)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 0.25 / piece)
€ 0.66
-62 %
€ 0.25
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

KK® 254

  • Content: 1 pc(s)
  • No. of rows: 1
  • Total number of pins: 8

Technical specifications

  • Please review product datasheet for further information.
Packaging type

Bag

Product type

Built-in pin strip (standard)

No. of rows

1

Connector system

wire-to-board

Series

254

Features

+ locking mechanism

CS

2.54 mm

Pins per row

8

Total number of pins

8

Nominal current

4 A

Nominal current - rounded value

4 A

Content

1 pc(s)

Connection

Soldering

Coating thickness (PCB side)

5.08 µm

Connector coating thickness

5.08 µm

Case material

Nylon (NL)

Manufacturer part #

22272081

Factory colour

Ecru white

Contact material

Brass

Board contact surface

Tin

Connector contact surface

Tin

Nominal voltage

500 V

RoHS-compliant

Yes

Connector orientation

Perpendicular (to the PCB)

Type

Molex MOL Power & Signal Sol.

Engineering Part No

AE-6410-08A(222)

Engineering Series Name

100 HDR FLK STR SQ N

Engineering Series No

06410

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 2447937 Molex Built-in pin strip (standard) 254 Total number of pins 8 Contact spacing: 2.54 mm 22272081 1 pc(s) Bag

User & Safety Instructions

User & Safety Instructions 2447937 Molex Built-in pin strip (standard) 254 Total number of pins 8 Contact spacing: 2.54 mm 22272081 1 pc(s) Bag

Circuit diagramm

Circuit diagramm 2447937 Molex Built-in pin strip (standard) 254 Total number of pins 8 Contact spacing: 2.54 mm 22272081 1 pc(s) Bag

Description

KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 8 Circuits, Tin (Sn) Plating
