Murrelektronik 5000-00501-1110000 5000-00501-1110000 A/D converter M12 socket No. of digital inputs: 1
EAN:
Part number:
Item no:
Product type
A/D converter
Interfaces
M12 socket
Type
5000-00501-1110000
Operating voltage
24 V DC
Height
32.3 mm
Datasheet (PDF)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 204.99 / piece)
€ 204.99
incl. VAT
Only available for business customers
14-day return policy includedTechnical specifications
- Analogueue input: M12 (socket) 5-pin, A-coded, shielded
- Resolution (analogue): 15 bits + sign
- Labeling: Laser-labeled
- Operating modes: COM2 (38.4 kbit/s)
- Data width: 16 bits / 2 bytes
- Diagnostics via IO-Link: Yes
- Diagnostics: Lower limit, upper limit, overtemperature, over voltage supply, under voltage supply, defective device, over current sensor supply, over-control
- Input filter: Yes, averaging, parameterizable N = 0...64
- Input resistance (analogueue): 232 Ω
- IO-Link: M12 (plug) 5-pin, A-coded
- Short circuit and overload: Yes
- Short-circuit protection sensor: Yes, permanent
- Material (housing): Plastic
- Measurement range (analogueue): 4...20 mA
- Measured value: Fixed
- Mean value filter: 1 byte
- Upper limit: 2 bytes
- Port class A
- Regenerative feedback: Yes, permanent
- Protection class IP65/IP67
- Sensor supply US: 24 V DC (EN 61131-2), max. 200 mA
- Specification: IO-Link V1.1
- Power consumption maximum 19 mA
- Temperature range -30...+70 °C (storage temperature -40...+85 °C)
- Surge protection 30 V DC
- Monitoring - Limit: Yes
- Monitoring - Temperature: Yes
- Monitoring - overvoltage: Yes
- Monitoring - undervoltage: Yes
- Under and over control: Yes
- Lower limit: 2 bytes
- Reverse polarity protection: Yes, permanent
- Polarity reversal protection module: Yes, permanent
- Conversion time (analogueue): Max. 5 ms
- Importance: 348 Na
- Product type
A/D converter
- Interfaces
M12 socket
- Type
5000-00501-1110000
- Operating voltage
24 V DC
- Height
32.3 mm
- Length
15 mm
- Width
77.2 mm
- No. of digital inputs
1
- Dim
(L x W x H) 15 x 77.2 x 32.3 mm
- Control LEDs
Yes
- Manufacturer part #
5000-00501-1110000
- Status LEDs
1
- UKCA
yes
